Meet the Proteus
Electric Hydrofoils
Lightweight
Environmentally friendly
Quiet
310
New Proteus 310
Proteus 310 is the first recreational boat, distinguished by its small size, ability to move at wing and displacement mode and fully electrical propulsion
Aviation Technology
in stabilisation
in stabilisation
Guided Flaps. Airplane allerons technology. Reduced drag and smooth ride over rough water conditions
Flight Modes for Versatility
Foiling mode for rough sea
Foiling high above the water
Flight Modes for Versatility
Foiling mode for calm sea
Foiling low above the water
Flight Modes for Versatility
Displacement mode
Maximum economy. Reduced speed, increased duration. Yacht hull lines allow effective displacement during cruising
Flight Modes for Versatility
Transport mode
All foils retracted. For easy loading and unloading
Manoeuver With One Finger
Industry Leading Propulsion
- Proprietary drive unit with 97% efficiency.
- Unitised motor - controller for increased efficiency and compactness
- Passive cooling technology.
- 5 kW / ~6.7HP input power, 14 kW / ~18.8HP peak performance. 30% lighter than analogues
- Smart Electric Steering System
- Easily control with little effort
- Fully electric with dynamic feedback
- Self-aligning when released
- Manual override ability
- Smart Electric Steering System
- Easily control with little effort
- Fully electric with dynamic feedback
- Self-aligning when released
- Manual override ability
- Proprietary drive unit with 97% efficiency.
- Unitised motor - controller for increased efficiency and compactness
- Passive cooling technology.
- 5 kW / ~6.7HP input power, 14 kW / ~18.8HP peak performance. 30% lighter than analogues
for range
battery chemistry
LiFePO4
capacity
10-14 kWh
in a cruise mode
at 22 knots. 85 NM range
at 22 knots. 85 NM range
4 hours
in a displacement mode at 5 knots. 45 NM range
9 hours
Designed
and durability
The power reserve is at least 2 times greater than other electric boats
Proteus 310
Other electric boats
Lake Como, Italy
Ibiza, Spain
Limassol, Cyprus
Technical specifications
Length
3100 mm
Draft
220 mm
with extended hydrofoils not on the move
800 mm
on the move in hydrofoils mode
350 mm
Net weight
145 kg
LiFePo4 battery capacity
15 kWh
Battery charging time
2 hours
Maximum speed in hydrofoil mode
26 kts
Maximum range
85 nautical miles
Metric
Imperial
20 kts
Cruising speed
0.6 m
Seaworthiness in hydrofoil mode without speed reduction
6 kW
El. engine power
250 kg
Payload weight in hydrofoil mode
160 mm
with retracted foils and stabilizer
430 mm
Freeboard
1400 mm
Width
Extreme toy
Uncomparable emotions
Extreme toy
Day cruiser
Uncomparable emotions
Uncomparable emotions
Day cruiser
Extreme toy
Uncomparable emotions
Extreme toy
Proteus 310 for Rental Operations
